חברת רדקו מייבאת ומשווקת משאבות תוצרת חברת WILO גרמניה אשר הינה המחברות המובילות באירופה לייצור משאבות ומערכות שאיבה.
חברת WILO מעסיקה מעל ל – 7800 עובדים. החברה הוקמה בשנת 1872 בור בית מלאכה לנחושת ופליז ומאז גדלה והתפתחה להיות מהחברות הגדולות בעולם לייצור משאבות.
חברת WILO מייצרת משאבות לענף הבניה , למערכות ניהול מים ותחומי תעשייה שונים.

Wilo-CronoNorm-NLG

Example NLG 200/315-75/4
NLG Series designation: Standard pump
200 Nominal diameter DN of pressure port
315 Nominal diameter of impeller [mm]
75 Rated motor power P2 [kW]
4 number of poles

Wilo-Sub TWI 8

• Mains connection: 3~400 V, 50 Hz
• Submerged operating mode: S1
• Fluid temperature:
o Hermetically cast motors: 3-20 °C or 3-30 °C (depending on type)
o Rewindable motors: 3-30 °C (depending on type)
• Minimum flow rate at motor: 0.1-0.5 m/s (depending on type)
• Max. sand content: 50 g/m3
• Max. number of starts: 10-20/h (depending on type)
• Max. immersion depth: 100 – 350 m (depends on type)
• Protection class: IP68
• Pressure connection: Rp 5



Wilo-Atmos GIGA-N

The standard pump for universal applications and a long service life.
The Wilo-Atmos GIGA-N is the entry-level model for glanded pumps. The wide range of motors and materials to choose from plus its wide temperature range from -20 to +140 °C make it a real all-rounder for a whole host of different applications.
Designed specifically for continuous duty, the pump also boasts a long service life thanks to its corrosion-resistant coatings and maintenance-free roller bearings. If maintenance is required, the spacer coupling ensures the mechanical seal can be replaced as quickly as possible. The speed of the Wilo-Atmos GIGA-N is controlled by a Wilo-EFC converter. It can be fitted with temperature and vibration monitoring for the pump bearing so that impending breakdowns can be recognised in good time.
With that in mind, Wilo also offers additional, complementary services ranging from commissioning through to maintenance, and the comprehensive full-service WiloCare package is designed to ensure optimal operational reliability via Wilo remote monitoring.



Wilo-EMU sprinkler pumps D…, K… and KM…

Example: Wilo-EMU KM 1300S-2a + NU 801-2/60
Hydraulics: KM 1300S-2a
KM1300 Hydraulics type
S Trimmed impeller
2 Number of hydraulic stages
A Defined impeller diameter
Motor: NU 801-2/60
NU Submersible motor (NU…, U…)
801 Size (6… = 6"; 8… = 8"; 9… = 10"; 12… = 12"; 15… = 16")
2 Number of poles
60 Package length (cm)



Wilo-CronoLine-IL

Example IL 40/160-4/2
IL In-line pump
40 Nominal diameter DN of the pipe connection
160 Nominal impeller diameter
4 Rated motor power P2 in kW
2 Number of poles



Wilo-CronoTwin-DL

Example DL 40/160‐4/2
DL In-line twin-head pump
40 Nominal diameter DN of the pipe connection
160 Nominal impeller diameter
4 Rated motor power P2 in kW
2 Number of poles



Wilo-Multivert MVIL

Example: MVIL 107N-16/E/3-400-50-2
MVIL Multistage vertical high-pressure centrifugal pump
1 Volume flow in m3/h
07 Number of impellers
N Standardised motor
16 Maximum operating pressure in bar
E Type of gasket E = EPDM
3 1 = 1~ (single-phase current) 3 = 3~ (three-phase current)
400 Connection voltage in V
50 Frequency in Hz
2 Number of poles
